Color | White Body, Black Screen |
Material | ABS+Glass Shell, Aluminum Casting Heater |
Mounting Type | Wall-mounted |
Control Mode | Touch Control, Remote Control |
Installation Environment Requirements | Circuit Breaker Switch > 40A |
Wire Requirements | ≥ 2.5mm ² Copper Core Wire |
Air Switch | ≥ 32A, Standard 1/2 Interface |
Temperature Range | 28-55 ℃/82.4-131 ℉ |
Automatic Power-off Protection Temperature | 60 ℃/140 ℉ |
Applicable Water Pressure | 0.04-0.6 mpa |
Waterproof Grade | IPX4 |
Flow Rate | (Generally Within) 0-5L/min |
Five Gear Power Adjustable | 1100W, 2200W, 3300W, 4400W, 5500W |
Nominal Plug | 220V(Without Plug) |
Power | 5500W |
Remote Control Battery | 2 * AAA Batteries (Not Included) |
Product Size | 21*15*5.5cm/ 8.26*5.90*2.16in |
Package Size | 26.5*25*9.5cm/ 10.43*9.84*3.74in |
Net Weight | 1.5kg/ 3.31lbs |
Gross Weight | 1.65kg/ 3.64lbs |
How to Change Gears:
1.Press the power key/power off key (the default mode for power on is frequency conversion mode)
2.Then long press the shutdown button for 6 seconds
3.The display screen shows 5, which can be adjusted by pressing the "down" key. 1 2 3 4 5 points represent five gears, namely 1100W/2200W/3300W/4400W/5500W
4.It can return to frequency conversion mode by long pressing for 6 seconds.
Notes:
1.Please note that this product cannot be installed without a ground wire. If you need to install it, please contact a professional to install the ground wire first.
2.To ensure product quality, each piece of equipment will be subject to a water heating test before delivery packaging. It is normal that a small number of watermarks may remain at the water inlet/outlet and packaging of the equipment, which is not a quality problem. Please understand.
3.During installation, please connect water and then electricity, and ensure that the water pressure is between 0.04-0.6MPa and the room temperature is above 0 ℃. The pipeline shall be arranged in a centralized way, and the hot water outlet shall not be too far away from the hot water electricity. Please install the power switch in the water and do not touch the cabinet.
