AU $664.50
Rechargeable Hydraulic Crimping Pliers Battery Powered Electric Hydraulic Pliers Electric Hydraulic Wire Crimper With the Ergonomic Handle
-
Brand:
CNCEST
-
Product Code:
JZONDT-000300AU
-
Availability:
Out Of Stock
Free Fast Shipping:
On all orders
Good Material
This product is made of 40Cr steel, Q235 steel, and engineering plastic, with the forging, finishing, and injection molding processes, which makes the product strong and durable, high hardness, anti-impact, anti-corrosion, and anti-rust.
Humanized Design
The ergonomic handle is easy to grip without slipping and can effectively reduce hand fatigue caused by long hours of work. The 360° swivel design and LED light make your operation more flexible and can help you work well in different situations.
OLED Screen
It can display the number of crimps, remaining power, and real-time temperature, which is convenient for you to operate, and also prevents the machine from burning out due to high temperature.
Save Time and Effort
Compared with manual hydraulic pliers, our electric one can be controlled by only one button, and it can be automatically reset when crimping is completed, which saves both time and effort.
Convenient to Carry
Equipped with a toolbox that can hold this product and its accessories, it is convenient for you to carry it to different work sites.
Easy Assembly
You just need to install the suitable die on it and then install the battery and you can start using it, which is very easy.
Pure Copper Motor
It provides strong power for the product, accelerates crimping speed, improves efficiency, and prolongs service life.
Battery Lock
It secures the battery to the bottom of the product, preventing it from falling off during use and making it easy to remove the battery.
Heat Dissipation Holes
They can ensure that the product can dissipate heat quickly and timely, avoiding the motor burning out due to the high temperature when working.
Application
It is suitable for electric power repair, construction work, copper terminal crimping, and aluminum terminal crimping.
Easy Assembly
You just need to install the suitable die on it and then install the battery and you can start using it, which is very easy.
Good Compatibility
The provided 12 different sizes of crimping dies(16, 25, 35, 50, 70, 95, 120, 150, 185, 240, 300, and 400mm²) can help you process different sizes of metal materials, making the product more widely used.
Specifications
-
Model:
EZ-400
-
Material:
40Cr Steel, Q235 Steel, Plastic
-
Process:
Forging, Finishing, Injection Molding
-
Color:
Black, Red
-
Style:
Modern
-
Motor Type:
Pure Copper Motor
-
Plug Type:
AU Standard
-
Assembly Required:
Yes
-
Number of Batteries:
2
-
Output Power:
400W
-
Voltage:
220V
-
Each Battery Capacity:
4.0Ah 18V
-
Charger:
21.5V 2A
-
Charging Time:
1.5-2h
-
Continuous Use Time:
1.5h
-
Maximum Output Force:
150KN
-
Working Stroke:
42mm/ 1.65in
-
Crimping Range:
400mm² (Copper Terminal), 300mm²(Aluminum Terminal)
-
Die Size:
16, 25, 35, 50, 70, 95, 120, 150, 185, 240, 300, 400mm²
-
Gross Weight:
15kg/ 33.07 lbs
-
Package Size:
60*50*14 cm/ 23.62*19.69*5.51in
-
Product Size:
44*8*32 cm/ 17.32*3.15*12.6 in
Package Included
-
1* Electric Hydraulic Pliers
-
2* Lithium Batteries
-
1* Battery Charger
-
12* Dies(One Installed)
-
1* Toolbox
-
1* English Manual
Specifications
| Model |
EZ-400
|
| Material |
40Cr Steel, Q235 Steel, Plastic
|
| Process |
Forging, Finishing, Injection Molding
|
| Color |
Black, Red
|
| Style |
Modern
|
| Motor Type |
Pure Copper Motor
|
| Plug Type |
AU Standard
|
| Assembly Required |
Yes
|
| Number of Batteries |
2
|
| Output Power |
400W
|
| Voltage |
220V
|
| Each Battery Capacity |
4.0Ah 18V
|
| Charger |
21.5V 2A
|
| Charging Time |
1.5-2h
|
| Continuous Use Time |
1.5h
|
| Maximum Output Force |
150KN
|
| Working Stroke |
42mm/ 1.65in
|
| Crimping Range |
400mm² (Copper Terminal), 300mm²(Aluminum Terminal)
|
| Die Size |
16, 25, 35, 50, 70, 95, 120, 150, 185, 240, 300, 400mm²
|
| Gross Weight |
15kg/ 33.07 lbs
|
| Package Size |
60*50*14 cm/ 23.62*19.69*5.51in
|
| Product Size |
44*8*32 cm/ 17.32*3.15*12.6 in |
Product Tips
Notes:
1.Please read the operating manual completely before use. And pay particular attention to the safety instructions included.
2.The fully charged time is approximately 1.5-2H, and it is recommended not to charge for too long to avoid battery capacity loss.
3.It is strictly prohibited to crimp without a crimping die to avoid damage to the clamp head.
4.Please allow the slight color difference caused by the shooting light and the 1-3 cm error due to manual measurement, and make sure you do not mind before ordering.
